Automatic Tissue Palletizer – High Efficiency · Gentle Handling · Labor Saving

 From case to pallet – seamlessly automated.

Automatic Tissue Palletizer

This equipment is specifically designed for the post-packaging stage of tissue production lines. It automatically stacks finished tissue
products (facial tissues, toilet rolls, boxed tissues, kitchen towels, etc.) onto pallets according to preset layer patterns and stacking heights,
replacing manual palletizing.

Main Functions:

• Automatically identifies incoming products with gentle gripping to avoid damaging tissue packaging

• Stacks layer by layer according to preset pallet patterns, compatible with various pallet sizes

• Integrates with upstream conveyors, stretch wrappers, and case sealers for a fully automated line


  Key Advantages:

  • Labor saving: one palletizer replaces 3–5 manual stackers

  • Reduced damage: gentle gripping structure minimizes packaging breakage

  • Neat stacking pattern: improves pallet storage and shipping stability

  • Quick changeover: one-click recipe recall for different product specifications


    Device model	ALX-GD30 PRO
    Designed arm span	1900mm
    Designed palletizing speed	6-12 times/minute (depending on product)
    Pallet size	L1200mm-W1200mm-H150mm
    Pallet placement method	Manual, one on the left and one on the right
    Robot load capacity	Maximum 30 kg including suction device (1900mm arm span model)
